Long Working Time Portable Barcode Scanner Wireless Mini Qr Code Reader for Warehouse
Model: WNI-6013B/V
Specifications
Long Working Time Portable Barcode Scanner Wireless Mini Qr Code Reader For Warehouse
2 Colors available: (1) black+blue (2) black+orange
|
Technical Parameters |
|
|
Wireless Specifications |
|
|
Communication mode |
Read-time mode/Inventory mode/Cache mode |
|
Communications |
433 to 440MHz |
|
Transmission range |
≤50M(In empty area 100M) |
|
Battery capacity |
2000mAh (Lithium battery) |
|
Charging time |
5H |
|
Electrical Characteristics |
|
|
Interface |
USB HID KEYBOARD/USB VCP |
|
Voltage requirement |
5VDC±10% |
|
Current consumption |
Max:120A |
|
Optical Characteristics |
|
|
Photo sensor |
CMOS array sensor |
|
Sensor Resolution |
648×480 pixels |
|
Light source |
white LED*1 |
|
Aim light source |
Red Bar LED |
|
Performance Characteristics |
|
|
Decode angle |
Pitch angle: ±65° Skew angle: ±60° Tilt angle:±180° |
|
Field of View |
34°(H)x 26°(V) |
|
Min resolution |
1D:127mm/5mil(pcs0.9) 2D:0.254mm/10mil(pcs0.9) |
|
Min.PCS value |
>25%UPC/EAN 13(13mil) |
