Desktop USB Payment CMOS 1D 2D QR Code Barcode Scanner
Model: WAI-1741
Specifications
Product Description
Specification
Interface Supported | USB HID KEYBOARD/USB VCP/RS-232 |
Input Voltage | DC 5V±10% |
Current | Max:190mA |
Image Sensor | CMOS Array Sensor |
light source | Sensor Resolution |
Scanning Angle | Pitch angle:±45°;Skew angle:±50°;Tilt angle:±180 |
Light Source | White LED |
Field of View | 53°(H),40°(V) |
Min Resolution | 〉30% UPC/EAN 13（13mil） |
Decode Capability | 1d: Codabar、Code 39、Code 32 Pharmaceutical (PARAF)、Interleaved 2 of 5、NEC 2 of 5、Code 93、 Straight 2 of 5 Industrial、Straight 2 of 5 IATA，Matrix 2 of 5，Code 11、Code 128、GS1-128、UPCA、UPC-E、EAN/JAN-8、EAN/JAN-13、MSI、GS1 DataBar Omnidirectional、GS1 DataBar Limited、 GS1 DataBar Expanded、China Post(Hong Kong 2 of 5)、Korea Post 2d：: DOT Code, Codeblock A、Codeblock F、PDF417、Micro PDF417、GS1 Composite Codes、QR Code、Data Matrix、MaxiCode、Aztec、HANXIN |
