Winson 10.1 Inch Win10 4G RAM + 64G ROM Supermarket Price Checker/POS Terminal with HD Camera
Model: YY52
Specifications
Winson YY52 Win10 Price Checker Machines 10.1 inch Touch Screen 2019 New Design Price Checker
|
Display system |
Display |
10.1 inch LED |
|
Display size |
10.1" |
|
|
Resolution |
1280X800 |
|
|
Brightness |
300 cd/m2 |
|
|
Host system |
System |
Windows7.1,8.1,10 |
|
Processor |
Intel® I5 @ 1.9-2.9GHz |
|
|
Memory RAM |
Standard 4GB |
|
|
Memory Flash |
Standard 64GB EMMC |
|
|
Network card |
3G+RJ45 + wireless WIFI, BT (optional) |
|
|
Features |
Scan code system |
Standard GB scan code reader |
|
RFID |
High frequency NFC, 14443A, 13.56(default), low frequency 125K,ultra high frequency (optional) |
|
|
Microphone |
Built-in microphone(optional) | |
|
Front HD camera |
1 million pixels | |
|
Internal expansion interface |
USB Port |
2*5 pin 2.0 USB Port*2 |
|
RS232 port |
2*5 pin 2.0 RS232 Port*2 |
|
|
GPIO port |
Support 4 lines input and output GPIO function | |
|
Expansion Bus |
1*SATA1 slot/1*MSATA slot |
|
|
External interface |
USB port |
USB host*2,USB OTG*2 |
| COM port | DB9 2*RS232 | |
|
HDMI |
Support the highest resolution 4096*2304@24/30HZ |
|
|
RJ45 |
2 * Realtek Gigabit LAN chip | |
|
POE power supply |
not support | |
|
VGA port |
1 * VGA display interface | |
|
Line out port |
1* Line out port(green) 3.5MM | |
|
MIC port |
1* MIC port(red) 3.5MM | |
| DC-in | DC 12V,5.5mm | |
|
Optional |
Base bracket | Desktop,Wall-mounted,vertical |
| RFID | Low frequency 125K,NFC,14443A,13.56 | |
| Read card module |
Low frequency 125K, high frequency NFC, 14443A, 13.56,UHF tag (choose one of three) |
|
|
Front HD camera |
2 million pixels (optional) | |
|
Back cover |
Metal | |
|
Physical properties |
Size | 266* 228 * 40mm |
| Weight | 2.32kg |
