Product detail





Display system







Display

10.1 inch LED

Display size

10.1"

Resolution

1280X800

Brightness

300 cd/m2





Host system









System

Windows7.1,8.1,10

Processor

Intel® Celeron J1900 @ 2.0GHz

Memory RAM

Standard 2GB

Memory Flash

Standard 32GB EMMC

Network card

RJ45 + wireless WIFI, BT



Features













Scan code system

Standard GB scan code reader

Microphone

Built-in microphone (optional)



Internal expansion interface







USB Port

2* USB 2.0 Port 2*5Pin

RS232 port

6 * RS232 serial port, of which only COM1 is 2 * 5 pin with 5V power supply, others are not electrified, COM3 supports RS485 / RS422 function.

GPIO port

Support 4 lines input and output GPIO function

Expansion Bus

1 MSATA slot



External interface

















USB port

2 * USB3.0 interface (the one above only supports USB2.0), 2 * USB 2.0 interface

COM port

DB9 2*RS232

HDMI

1* HDMI display interface

RJ45

1 * Realtek Gigabit LAN chip

POE power supply

not support

VGA port

1 * VGA display interface

Line out port

1* Line out port(green) 3.5MM

MIC port

1* MIC port(red) 3.5MM

DC-in

DC 12V,5.5mm







Optional













Base bracket

Desktop,Wall-mounted,vertical

RFID

Low frequency 125K,NFC,14443A,13.56

vivoPAY

Can support global credit card payment, flash payment, scan code payment

Front HD camera

2 million pixels (optional)

Back cover

Metal,plastic

Physical properties



Size

266* 228 * 40mm

Weight

2.32kg
