10.1 Inch Widescreen Touch Screen POS System All in One POS Terminal Point of Sale POS Machine
Model: 10.1inch
Specifications
New Design Price Checker Barcode Scanner Restaurant Supermarket Oem Pos System
|
Display system
|
Display |
10.1 inch LED |
|
Display size |
10.1" |
|
|
Resolution |
1280X800 |
|
|
Brightness |
300 cd/m2 |
|
|
Host system
|
System |
Windows7.1,8.1,10 |
|
Processor |
Intel® Celeron J1900 @ 2.0GHz |
|
|
Memory RAM |
Standard 2GB |
|
|
Memory Flash |
Standard 32GB EMMC |
|
|
Network card |
RJ45 + wireless WIFI, BT |
|
|
Features
|
Scan code system |
Standard GB scan code reader |
|
Microphone |
Built-in microphone (optional) |
|
|
Internal expansion interface
|
USB Port |
2* USB 2.0 Port 2*5Pin |
|
RS232 port |
6 * RS232 serial port, of which only COM1 is 2 * 5 pin with 5V power supply, others are not electrified, COM3 supports RS485 / RS422 function. |
|
|
GPIO port |
Support 4 lines input and output GPIO function |
|
|
Expansion Bus |
1 MSATA slot |
|
|
External interface
|
USB port |
2 * USB3.0 interface (the one above only supports USB2.0), 2 * USB 2.0 interface |
|
COM port |
DB9 2*RS232 |
|
|
HDMI |
1* HDMI display interface |
|
|
RJ45 |
1 * Realtek Gigabit LAN chip |
|
|
POE power supply |
not support |
|
|
VGA port |
1 * VGA display interface |
|
|
Line out port |
1* Line out port(green) 3.5MM |
|
|
MIC port |
1* MIC port(red) 3.5MM |
|
|
DC-in |
DC 12V,5.5mm |
|
|
Optional
|
Base bracket |
Desktop,Wall-mounted,vertical |
|
RFID |
Low frequency 125K,NFC,14443A,13.56 |
|
|
vivoPAY |
Can support global credit card payment, flash payment, scan code payment |
|
|
Front HD camera |
2 million pixels (optional) |
|
|
Back cover |
Metal,plastic |
|
|
Physical properties
|
Size |
266* 228 * 40mm |
|
Weight |
2.32kg |
